Smart Energy Management System Integrates Solar Wind And Diesel Generator Inputs 5.5. Safe And Durable Energy Storage Unit With Automatic Fire

Ask Lasest Price
Brand Name :	1stess
Model Number :	EnerCube
Certification :	1
Price :	negotiable
Payment Terms :	L/C,T/T
Supply Ability :	10 containers per month
Delivery Time :	60-90 days

Add to Cart

Product Details
Company Profile

Smart Energy Management System Integrates Solar Wind And Diesel Generator Inputs 5.5. Safe And Durable Energy Storage Unit With Automatic Fire

Product Features:

Modular design
All-in-One design
Supports AC and Dc coupling
Standard 20HQ container
Classification society certification
7*24 hours monitoring
Online assisted O&M

Product Parameters:

Type	P400C860	P500C1075	P600C1290	P700C1505	P800C1720
DC side parameters
Cell type &capacity	LiFePO₄-280Ah
Battery module type	1P20S
System configuration	4*1P240S	5*1P240S	6*1P240S	7*1P240S	8*1P240S
Capacity(BOL)	860kWh	1075kWh	1290kWh	1505kWh	1720kWh
AC side parameters
Grid type	3P4W+PE
Rated output power	400kW	500kW	600kW	700kW	800kW
Rated voltage	AC400V
Rated frequency	50/60(±5)Hz
Maximum output current	577A	722A	866A	1010A	1155A
Harmonics	<3%(@rated power)
Overload capacity	110%,10mins;120%,60s
General parameters
Isolation transformer	No
Protection level	Outdoor installation (Battery cabinet:IP55,Electrical room:IP34)
Container anti-corrosion grade	C3
Operation temperature*	-20℃~50℃
Relative humidity	0~95%(non-condensing)
Permissible altitude**	<2000m
Cooling method	Battery cabinet:HVAC,Electrical room:forced air cooling
Fire fighting system	FAS &FM200/Novec1230
Noise emission	≤75dB
Dimension (WDH)	20HQ container (6058mm2438mm2896mm)
Maximum weight	24500kg
Communication interface	Ethernet
Communication protocol	Modbus TCP/IP
Warranty	5 years (can be extended to 10 years)Warranty
Certification	System:UN3536,LVD,EMC,RoHS Cell:IEC62619,UL1973,UL9540A PACK:UN38.3 PCS:G99,EN50549,AS4777.2,VDE4105

1. Canada

Arctic-Grade Cold Weather Operation: Reliable start-up and operation down to -20°C, essential for remote communities and mining operations in Northern Canada.
Heavy-Duty Construction: Built to withstand heavy snow loads and the rigors of transport on rough, remote access roads.
Off-Grid Community Energy Solution: Integrates with local diesel, solar, or wind resources to create stable, cleaner microgrids, reducing reliance on imported fuel.
Indoor/Outdoor Flexibility: The outdoor installation rating (IP55/IP34) provides siting flexibility in harsh Canadian winters.
Supports Provincial Renewable Initiatives: Effectively stores intermittent renewable energy, helping provinces meet their green energy mandates.
High-Cycle Lifetime for Daily Use: The robust LiFePO4 chemistry is suited for daily charge/discharge cycles in both grid-tied and off-grid applications.
Comprehensive Winterization: The HVAC system in the battery cabinet is designed to manage both cooling and heating needs in extreme climates.
Emergency Power for Critical Infrastructure: Provides backup for hospitals, communication towers, and emergency services during winter storms.
Alignment with Canadian Standards: System certifications provide a pathway to compliance with Canadian Electrical Code and other standards.
Low Total Cost of Ownership: The minimal O&M requirements and long service life result in a favorable economic model over its lifetime.

2. South Africa

Load-Shedding Mitigation: Provides immediate and reliable backup power during scheduled and unscheduled power cuts (load-shedding), keeping businesses operational.
High ROI for C&I Sector: Rapid payback through demand charge reduction and energy arbitrage in a market with high and escalating electricity prices.
Dust and Moisture Protection: The IP55 rating is critical for protecting battery systems from the pervasive dust in many regions and seasonal rains.
Hybridization for Mines & Industry: Easily couples with diesel generators and solar PV to create cost-effective and more resilient power solutions for the mining sector.
Rapid Response to Grid Instability: The sub-200ms response time can help stabilize local mini-grids and support fragile municipal grids.
Remote Management Capability: Online monitoring allows for central management of multiple distributed assets across the country.
Reduces Carbon Tax Liability: Helps large emitters reduce their carbon footprint and associated tax burdens under South African regulations.
Simple Transport via Major Ports: The containerized design simplifies shipping through ports like Durban and Cape Town.
Mitigates Technical Skills Shortage: The plug-and-play design and remote O&M reduce dependency on highly specialized local installation crews.
Durable for High-UV Environments: The materials and paintwork are selected to withstand prolonged exposure to intense sunlight.

3. France

Optimized for Nuclear Flexibility: Can store low-cost nuclear power during off-peak hours and discharge during peaks, supporting the national grid's load profile.
Compliant with French Grid Codes: PCS certifications ensure adherence to specific French technical requirements for grid interconnection.
High Energy Density for Limited Space: The high kWh capacity within a standard container is ideal for sites with space constraints in urban France.
Supports Local Energy Communities: An ideal platform for boucles locales (energy loops) and collective self-consumption projects.
Superior Fire Safety Standards: The FFS with environmentally friendly agents like Novec1230 meets the high safety expectations of French regulators.
Efficient Cooling for Temperate Summers: The forced air and HVAC cooling is more than adequate for the French climate, ensuring high efficiency.
Integration with Agri-Voltaics: Can store solar energy generated from farms with dual-use solar panels (agri-voltaics).
Advanced Data Security: Secure Ethernet communication protocols protect system data integrity.
Promotes Sobriété Énergétique: Empowers businesses and communities to achieve energy sobriety through smarter management and storage.
Long-Term Industrial Warranty: The 10-year warranty option aligns with the long-term investment horizon of French industrial players.

4. Italy

Maximizes Solar Self-Consumption: Perfect for the booming Italian residential and commercial solar market, maximizing the value of generated power under the Scambio sul Posto scheme.
Suitable for Mountainous Terrain: Operates efficiently at altitudes up to 2000m, making it suitable for installations in the Alps and Apennines.
Power Quality for Sensitive Historical Sites: Provides clean, stable power to protect sensitive equipment in historical buildings, museums, and data centers.
Reduces Capacity Charges: Helps businesses avoid steep maggiorazioni di capacit (capacity charges) on their electricity bills.
Resilience to Extreme Heat Events: Performs reliably during the summer heatwaves that are becoming more frequent in Italy.
Aesthetic and Compact Footprint: The neutral container design is less intrusive than custom-built solutions, an important consideration in areas of natural beauty.
Fast Installation for Time-Sensitive Incentives: The plug-and-play nature allows for quick project completion to meet incentive program deadlines.
Integration with Agricultural Biogas: Can be paired with Italy's widespread agricultural biogas plants to provide firm, dispatchable power.
Robust Against Voltage Fluctuations: Handles grid voltage variations common in some Italian rural networks.
Proven Safety for Dense Urban Areas: The comprehensive safety features minimize risk in densely populated urban and semi-urban settings.

5. Spain

Ideal for High Solar Irradiation: Captures and stores Spain's abundant solar energy, providing power through the evening and night.
Supports Energy Communities: The modular system is perfectly scaled for shared energy projects within residential and industrial communities.
Durable for Coastal Installations: The C3 anti-corrosion grade is essential for long-term reliability in Spain's extensive coastal regions.
Grid Services Revenue Stream: The fast response time enables participation in the Spanish ancillary services market for additional revenue.
Reduces Grid Connection Costs: For new developments, a smaller grid connection can be requested by using the BESS for peak shaving.
Efficient in Dry and Hot Climates: The cooling system is optimized to handle the hot, dry summers of central and southern Spain without excessive energy use.
Compliant with Spanish Royal Decrees: The system's features support compliance with local regulations for self-consumption and storage.
Backup for Tourism Industry: Ensures uninterrupted power for hotels, resorts, and restaurants, which are critical to the Spanish economy.
Easy Permitting Process: The standardized, certified container can simplify the local permitting and approval process.
Long-Life Battery Chemistry: LiFePO4 cells offer a long cycle life and calendar life, ensuring a strong return on investment.
