1.5kW 24V Pure Sine Wave Hybrid Inverter IP65 Waterproof MPPT Charger 60A Solar Input

Ask Lasest Price
Brand Name :	1stess
Model Number :	EM (PV60-500VDC) 550048L
Certification :	CE, IEC
Price :	To be negotiated
Payment Terms :	L/C, T/T
Supply Ability :	2000 pieces per month
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

1.5kW 24V Pure Sine Wave Hybrid Inverter IP65 Waterproof MPPT Charger 60A Solar Input

Product Description

Lithium battery activation function by PV or Utility
Compatible work with lifepo4 battery via Rs485
Pure sine wave
Powerfactor 1.0
PVinput Voltage 60Vdc-500Vdc
Built-inMPPT60A/100A/120A
Capable to work without battery
Detachable dustcover for harsh environment
WiFiremote monitoring optional
Support multiple output priority:UTL,SOL,SBU, SUB
EQ function to optimize battery performance and extend lifecycle

Technical Parameters

Model Number	EM3500-24L	EM5500-48L	EM6200-48L
Place of Origin	China	China	China
Mounting Method	Wall Bracket	Wall Bracket	Wall Bracket
Nominal Battery Voltage (V)	24VDC	48VDC	48VDC
Lithium Battery activation	YES( By PV or Utility)	YES( By PV or Utility)	YES( By PV or Utility)
Nominal Voltage	230VAC	230VAC	230VAC
Lithium Battery communication	YES(RS485)	YES(RS485)	YES(RS485)
Frequency	50/60Hz	50/60Hz	50/60Hz
Waveform	Pure Sine wave	Pure Sine wave	Pure Sine wave
Solar Charger Type	MPPT	MPPT	MPPT
Communication Interface	RS232+RS485	RS232+RS485	RS232+RS485
PV Array MPPT Voltage Range	60VDC~500VDC	60VDC~500VDC	60VDC~500VDC
Surge Power	7000VA	11000VA	1240VA
Size	358295100mm	438295105mm	438295105mm
Weight	7kg	9kg	9kg
Operating Temperature Range	(-10'℃ to 50℃)	(-10'℃ to 50℃)	(-10'℃ to 50℃)

Hybrid solar inverter installation diagram

Applications

The Off Grid Hybrid Solar Inverter comes with a communication interface, RS232, which allows users to connect it to a computer and monitor and control its performance. This feature makes it easy to keep track of the power output and to troubleshoot any issues that may arise.

The Hybrid Solar Inverter is suitable for a wide range of applications. It can be used in homes, offices, and other buildings that require a reliable power supply. The Off Grid Hybrid Solar Inverter is also suitable for use in remote areas where there is no access to the power grid. It can be used to power lighting, appliances, and other electrical devices.
